Gantry power assisted manipulator, the manipulator is suspended below the track, and the track is fixed on the truss. The manipulator is moved through the guide rail and sliding trolley, which has a wide working range, can serve multiple stations, and can complete the loading and unloading work of multiple stations.
Gantry power assisted manipulator features:
Truss manipulator parameters
| Model | Working air pressure (Mpa) | Maximum service radius (mm) | Maximum lifting capacity (kg) | Maximum lifting stroke (mm) |
| TLJXS-LMJ-50 | 0.5-0.8 | 2500 | 50 | 500-2000 |
| TLJXS-LMJ-100 | 0.5-0.8 | 2500 | 100 | 500-2000 |
| TLJXS-LMJ-200 | 0.5-0.8 | 2500 | 200 | 500-2000 |
Based on the product information, usage conditions, installation site environment, and layout provided by the customer, we provide customized solutions for free.
All accessories have passed factory testing and meet specifications, enabling continuous and unobstructed operation.
For complex on-site conditions or special workpieces, Tongli can provide on-site investigation and measurement services to make appropriate solutions.
Having a professional equipment installation team, with excellent skills and tools, we provide fast and reliable robotic arm installation services.
